Personal Transportation Battery



How to alleviate traffic pressure, especially peak period congestion in road?


We are glad to see some innovative zero-emission and high-efficient personal transportation solutions on roads in recent years. Our team maintains close cooperation with our partners to supply high-quality and reliable Li-ion battery solutions to support their ambitious plans.



We supply public and customized batteries for e-bikes, pedelecs, e-scooters and cargo-bikes. We never stop helping to reduce carbon emissions and improve resident traffic efficiency.



Our typical Lithium-ion battery solutions for e-bikes, pedelecs, e-scooters and cargo-bikes.



Voltage (V)

Model #

Capacity* (Ah)

Energy (Wh)

Cell Configuration

Charge Port

Discharge Port

Dimensions (mm)

36

SSE-113-C50

13

468

10S*5P*

DC 2.1

5 Pin

362 x 90.3 x 92.7

36

SSE-085-C40

10.4

374.4

10S*4P*

DC 2.1

6 Pin

420 x 76.4 x 68

36

SSE-053-C60

15.6

561.6

10S*6P*

3 Pin

4 Pin

414 x 114 x 75

36

SSE-077-C60

15.6

561.6

10S*6P*

3 Pin

4 Pin

367.4 x 90.3 x 111

36

SSE-046-C50

13

468

10S*5P*

DC 2.1

4 Pin

367.5 x 90.3 x 90

36

SKY-01-C40

10.4

374.4

10S*4P*

DC 2.1

5 Pin

340 x 113 x 84

36

SKY-02-C50

13

468

10S*5P*

DC 2.1

5 Pin

362 x 114 x 95.3

36

XHXH-40CF-C40

10.4

374.4

10S*4P*

DC 2.1

5 Pin

412 x 92 x 100

36

HXH-52CF-C50

13

468

10S*5P*

DC 2.1

5 Pin

432 x 92 x 109

36

IE-MINI-C40

10.4

374.4

10S*4P*

DC 2.1

2 Pin

430 x 65 x 86

36

IE-PRO-C50

13

468

10S*5P*

DC 2.1

2 Pin

430 x 106 x 65

36

DP-6-C60

15.6

561.6

10S*6P*

DC 2.1

5 Pin

368 x 90 x 113

48

SSE-125-C52

10.4

499.2

13S*4P*

DC 2.1

6 Pin

441 x 85 x 72

48

SSE-113-C52

10.4

499.2

13S*4P*

DC 2.1

5 Pin

362 x 90.3 x 92.7

48

SSE-126-C39

7.8

374.4

13S*3P*

DC 2.1

6 Pin

399 x 75 x 90

48

SSE-101-C65

13

624

13S*5P*

DC 2.1

6 Pin

487 x 97 x 68

48

SSE-015-C65

13

624

13S*5P*

DC 2.1

4 Pin

389 x 75 x107.5

48

IG-PLUS-C52

10.4

499.2

13S*4P*

DC 2.1

6 Pin

426 x 90 x 87

48

IB-PLUG-C52

10.4

499.2

13S*4P*

DC 2.1

6 Pin

434 x 96 x 68

48

ID-PLUS-C52

10.4

499.2

13S*4P*

DC 2.1

6 Pin

456 x 104 x 65

50.4

EM*4838

38.4

1,935

14S*12P*

2 Pin + 6 Pin

2 Pin + 6 Pin

310 x 190 x 165

50.4

EM*4860

60.0

3,024

14S*12P*

2 Pin + 6 Pin

2 Pin + 6 Pin

350 x 210 x 175

61.2

EM*6038

38.4

2,350

17S*12P*

2 Pin + 6 Pin

2 Pin + 6 Pin

370 x 190 x 165

61.2

EM*6060

60.0

3,672

17S*12P*

2 Pin + 6 Pin

2 Pin + 6 Pin

420 x 210 x 175

72

EM*7238

38.4

2,764

20S*12P*

2 Pin + 6 Pin

2 Pin + 6 Pin

400 x 190 x 165

72

EM*7260

60.0

4,320

20S*12P*

2 Pin + 6 Pin

2 Pin + 6 Pin

450 x 210 x 175



*Capacity - calculation is based on Li-ion cylindrical 2600mAh, 3200mAh, 3500mAh, 5000mAh cells.

*S - series, *P - parallel

*EM - electric motorcycle battery


Contact us today to customize your battery. Please fill in below form with your information. We will study this information and propose a cost-efficient battery system to you as soon as possible.
