Leisure & Marine



DNP's Lithium Iron Phosphate battery system with smart Battery Management System technology will revolutionize your leisure experience. We build our batteries to perform better, last longer and provide the deliverable power needed for weekend adventures or full-time boondocking.


Our batteries were designed as drop-in replacements for the most common lead acid sizes on the market, so you can find from 12V to 48V lithium deep cycle battery that works best for you.


We've performed extensive testing on the RV industries major suppliers to ensure compatibility. Brands like Victron Energy, Magnum, CTEK, Sterling Power, Xantrex, MINN KOTA and many more make products that excel in a lithium power system. Our experience enables us to assess your current batteries and components and allows us to build a Lithium battery system to power your future adventures. Whether it's in a motorized, towable, truck camper, or trolling motor. DNP has the batteries, components and knowledge for your lithium upgrade.






Descriptions

DCU24100BL

DCU160BL

DCU200BL

DCU100BL

DCU100B-V2

DCU160B

DCU200B

Main Parameters

Rated Voltage

25.6V

12.8V

12.8V

12.8V

12.8V

12.8V

12.8V

Rated Capacity

100Ah

160Ah

200Ah

100Ah

100Ah

160Ah

200Ah

Energy

2.56kWh

2.04kWh

2.56kWh

1.28kWh

1.28kWh

2.04kWh

2.56kWh

Life Cycle* @ 25

3,500 times

3,500 times

3,500 times

3,500 times

3,500 times

3,500 times

3,500 times

Battery Chemistry

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

Charge Current

Fast Charge

80A

100A

120A

80A

80A

100A

120A

Standard Charge

50A

80A

100A

50A

50A

80A

100A

Discharge Current

Continuous Discharge

100A

160A

200A

100A

100A

150A

150A

Max Discharge

150A

250A

250A

120A

120A

200A

200A

Peak Discharge

200A for 5s

300A for 5s

300A for 5s

200A for 5s

200A for 5s

250A for 5s

250A for 5s

Environment

Charge Temperature

0 ~ 50

0 ~ 50

0 ~ 50

0 ~ 50

0 ~ 50

0 ~ 50

0 ~ 50

Discharge Temperature

-20 ~ 60

-20 ~ 60

-20 ~ 60

-20 ~ 60

-20 ~ 60

-20 ~ 60

-20 ~ 60

Storage Temperature

-20 ~ 45

-20 ~ 45

-20 ~ 45

-20 ~ 45

-20 ~ 45

-20 ~ 45

-20 ~ 45

Communication

Protocol

RS485

RS485

RS485

RS485

RS485

RS485

RS485

Bluetooth

BEL4.2

BLE4.2

BLE4.2

BLE4.2

BLE4.2

BLE4.2

BLE4.2

Battery Bank

Series

Prohibited

Max 2pcs

Max 2pcs

Max 2pcs

Max 4pcs

Max 4pcs

Max 4pcs

Parallel

Max 2pcs

Max 2pcs

Max 2pcs

Max 4pcs

Max 4pcs

Max 4pcs

Max 4pcs

Mechanics

Cell configuration

8S*1P*

4S*2P*

4S*2P*

4S*1P*

4S*1P*

4S*2P*

4S*2P*

Dimensions (mm)

355/L x 260/W x 195/H

355/L x 260/W x 195/H

355/L x 260/W x 195/H

315/L x 176/W x 187/H

328/L x 177/W x 218/H

483/L x 170/W x 240/H

522/L x 238/W x 223/H

Ingress Rating

IP54

IP54

IP54

IP56

IP56

IP56

IP56

Cooling

Natural Convection

Natural Convection

Natural Convection

Natural Convection

Natural Convection

Natural Convection

Natural Convection

Weight

25Kg

22Kg

25Kg

11.5Kg

11.9Kg

21.5Kg

24.5Kg

Shipping Classification

UN38.3

Hazard Class 9

Hazard Class 9

Hazard Class 9

Hazard Class 9

Hazard Class 9

Hazard Class 9

Hazard Class 9

*S - series

*P - parallel

*Life Cycle is based on 90% DOD with standard charge, discharge current at 25 degrees Celsius.
