Leisure & Marine



DNP’s Lithium Iron Phosphate battery system with smart Battery Management System technology will revolutionize your leisure experience. We build our batteries to perform better, last longer and provide the deliverable power needed for weekend adventures or full-time boondocking.



Our batteries were designed as drop-in replacements for the most common lead acid sizes on the market, so you can find from 12V to 48V lithium deep cycle battery that works best for you.


We’ve performed extensive testing on the RV industries major suppliers to ensure compatibility.Brands like Victron Energy, Magnum, CTEK, Sterling Power, Xantrex, MINN KOTA and many more make products that excel in a lithium power system. Our experience enables us to assess your current batteries and components and allows us to build a Lithium battery system to power your future adventures. Whether it’s in a motorized, towable, truck camper, or trolling motor. DNP has the batteries, components and knowledge for your lithium upgrade.






Descriptions

DCU2460B

DCU3630B

DCU4830B

DCU1270B

DCU12100B

DCU12160B

DCU12200B

Main Parameters

Rated Voltage

25.6V

38.4V

51.2V

12.8V

12.8V

12.8V

12.8V

Rated Capacity

60Ah

30Ah

30Ah

70Ah

100Ah

160Ah

200Ah

Energy

1.53kWh

1.15kWh

1.53kWh

0.89kWh

1.28kWh

2.04kWh

2.56kWh

Life Cycle* @ 25

3,500 times

3,500 times

3,500 times

3,500 times

3,500 times

3,500 times

3,500 times

Battery Chemistry

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

LiFePO4 (LFP)

Charge Current

Fast Charge

50A

25A

25A

55A

80A

90A

90A

Standard Charge

30A

15A

15A

35A

50A

60A

60A

Discharge Current

Continuous Discharge

30A

15A

15A

35A

50A

80A

80A

Max Discharge

90A

45A

45A

70A

100A

140A

140A

Peak Discharge

120A for 5s

90A for 5s

90A for 5s

150A for 5s

200A for 5s

200A for 5s

200A for 5s

Environment

Charge Temperature

0 ~ 50

0 ~ 50

0 ~ 50

0 ~ 50

0 ~ 50

0 ~ 50

0 ~ 50

Discharge Temperature

-20 ~ 60

-20 ~ 60

-20 ~ 60

-20 ~ 60

-20 ~ 60

-20 ~ 60

-20 ~ 60

Storage Temperature

-20 ~ 45

-20 ~ 45

-20 ~ 45

-20 ~ 45

-20 ~ 45

-20 ~ 45

-20 ~ 45

Communication

Protocol

RS485

RS485

RS485

RS485

RS485

RS485

RS485

Bluetooth

BEL4.0

BLE4.0

BLE4.0

BLE4.0

BLE4.0

BLE4.0

BLE4.0

Battery Bank

Series

Prohibited

Prohibited

Prohibited

Max 4pcs

Max 4pcs

Max 4pcs

Max 4pcs

Parallel

Max 4pcs

Max 4pcs

Max 4pcs

Max 4pcs

Max 4pcs

Max 4pcs

Max 4pcs

Mechanics

Cell configuration

8S*2P*

12S*1P*

16S*1P*

4S*1P*

4S*1P*

4S*2P*

4S*2P*

Dimensions (mm)

260/L x 180/W x 276/H

260/L x 180/W x 276/H

260/L x 180/W x 276/H

258/L x 175/W x 190/H

328/L x 177/W x 218/H

483/L x 170/W x 240/H

522/L x 238/W x 223/H

Ingress Rating

IP67

IP67

IP67

IP67

IP67

IP67

IP67

Cooling

Natural Convection

Natural Convection

Natural Convection

Natural Convection

Natural Convection

Natural Convection

Natural Convection

Weight

15.2Kg

12.5Kg

15.2Kg

7.8Kg

11.9Kg

21.5Kg

24.5Kg

Shipping Classification

UN38.3

Hazard Class 9

Hazard Class 9

Hazard Class 9

Hazard Class 9

Hazard Class 9

Hazard Class 9

Hazard Class 9

*S - series

*P - parallel

*Life Cycle is based on 0.5C charge and 0.5C discharge at 25 degrees Celsius.
